OndaPIÙ: corrugated modular system in multiwall polycarbonate

CORRUGATED UV-PROTECTED MULTIWALL POLYCARBONATE MODULAR SYSTEM FOR SKYLIGHTS, FLAT AND CURVED TRANSPARENT COVERINGS OR IN CONJUNCTION WITH ASBESTOS CEMENT SHEETS.

OndaPIÙ is a triplewall polycarbonate sheet extruded in the EURO 177/51mm wave corrugation and available in the thickness of 4 and 6mm. It is also available in the 76/18 profile, thickness 6 mm.

The sheets are extruded in seven complete corrugated waves, designed to better guarantee the tightness on the side and edge overlaps on skylights and flat roof coverings. The system also allows a perfect side overlap to asbestos cement sheets, usually used for coverings, vertical skylights and curved roofing coverings with a radius of R 3500.

Strengths

  • Available flat or curved
  • Good light transmission
  • Possibility of lengthwise/crosswise overlapping
  • UV protection
  • Heat sealing
  • Complete accessory system

Documents and Assembly Drawings

To view the documents and assembly diagrams, please access the reserved area.

Constructions

Features

  • Available colors:
    Satined clear and opal
  • Customizable colors on request:
    smoky-brown, blue, green, red, yellow, orange, light blue, fuchsia, pearly.
  • Minimum order quantity:
    400 sqm
  • Product certifications:
    Fire class
    Shock tests 1200 Joules
